Titration pump and supplies supporting DSP-2 four-channel titration Pump extension unit

Model: DSP-2 model for the expansion of this type must be connected to the host computer to be able to use DSP-1

&Nbsp; for

And the source of MARINE SOURCES micro titration pump is mainly used for domestic mariculture fish tank.

&Nbsp; for

Intelligent micro-computer chip designed to provide timing, quantitative, and accurate to add various elements of marine biological need, such as calcium, magnesium, kh improver, other types of trace element additives add supplements. By adding automation, save manpower add annoyance, avoidance added result of manpower caused by the leakage of Canada, excess or inadequate mistakes.

&Nbsp; for

Titration pump sea source host DSP-1 provides three titration head with a separate power adapter.

Extension unit DSP-2 has four titration head, without the power adapter, no additional power supply, only need to connect to the host DSP-1, use the computer’s power can be switched on to work.

Host connection type DSP-1 to the extension machine model DSP-2, can achieve up to 11 head of work settings. See the following connection scheme.

&Nbsp; for

DSP-1 is a mainframe computer with a 3-channel, with control.

DSP-2 is an extension of a 4-channel, it must be driven by the DSP-1.

DSP-1 can drive up to two DSP-2, see the following recommendations connectivity solutions

Option One: a computer with a DSP-1, may have a 3-channel control function titration

Option Two: A DSP-1 + a DSP-2, 7-channel composition with computer having a control function titration

Option Three: A DSP-1 + two DSP-2, with a composition having a 11-channel computer controlled titration function

More than three programs, only one power supply.

DSP-2 alone can not achieve computer-controlled titration functions.

&Nbsp; for

&Nbsp; for

&Nbsp; for

&Nbsp; for

Source sea titration pump has the following characteristics

1 DSP-2 extension models, must be connected to DSP-1 use, and not a separate power supply.

2 military grade micro-computer chip, circuit products stable, dropping precision

3 selection of five high torque long longevity quiet motor.

4 pump shell with automotive instrument-level high-strength self-lubricating plastic.

5 has a power save function to avoid blackouts trouble need to repeat the set.

6 medical grade high quality and longevity Buret, long life, does not contain harmful elements.

7 computer control panel waterproof design.

8 LCD liquid crystal display, interactive operator control interface is friendly.

&Nbsp; for

&Nbsp; for

Model: DSP-2

Product Power: AC100-240V, you need to link to the host using the DSP-1

Product size: 230 * 130 * 75 mm

Working mode: interval cycles after dropping, dropping a single set flow rate and intervals, the product will be in accordance with the intervals set number of hours of intermittent dripping. Single drops flow 00-99ml adjustable, adjustable time interval 00-99 hours, and the other with automatic anti-interference mode, the same time there are two or more head needs dropping, the pump head is automatically converted to the anti-interference mode, the pump head will be different queuing drip drip after the previous head, a head after waiting two minutes after drip, drip while avoiding different elements may produce a variety of physical or chemical reactions and interference .
